Removal and Installation

WARNING: This page is about a different car, the 2003 Ford Pickup, 2003 Ford F550 Super Duty, 2003 Ford F450 Super Duty, 2003 Ford Excursion, and 2003 Ford Cab & Chassis. However, it is still accessible from the selected car via links, so may be relevant.

NOTE: RH shown; LH similar.

Remove the rear lamp (13404).
1. Remove the bolts.
2. Pull the lamp assembly rearward to release the clips.
3. If necessary, install a new bulb.

  Fig 1: Removing Rear Lamp
  Courtesy of FORD MOTOR CO.
To install, reverse the removal procedure.
