Removal and Installation

WARNING: This page is about a different car, the 2003 Ford Pickup, 2003 Ford F550 Super Duty, 2003 Ford F450 Super Duty, 2003 Ford Excursion, and 2003 Ford Cab & Chassis. However, it is still accessible from the selected car via links, so may be relevant.

Disconnect the battery ground cable. Refer to BATTERY, MOUNTING AND CABLES .
Raise the and support vehicle.
Remove the nuts.

Fig 1: Removing Nuts
Courtesy of FORD MOTOR CO.
Remove the right front wheel and tire. Refer to WHEELS & TIRES .
Remove the right front inner fender well.
Remove the nuts, the exhaust manifold and the gasket. Discard the gasket.

Fig 2: Removing Right Front Inner Fender Well
Courtesy of FORD MOTOR CO.
Clean and inspect the exhaust manifold. Refer to ENGINE SYSTEM - GENERAL INFORMATION .
To install, reverse the removal procedure.
