Crankshaft Rear Seal: Removal

WARNING: This page is about a different car, the 2003 Ford Pickup, 2003 Ford Excursion, and 2003 Ford Cab & Chassis. However, it is still accessible from the selected car via links, so may be relevant.

Disconnect the battery ground cable. Refer to BATTERY, MOUNTING AND CABLES .

NOTE: It is not necessary to remove the transmission from the jack.

Remove the flexplate. Refer to FLEXPLATE - Automatic Transmission or FLYWHEEL - Manual Transmission .
Use the special tools to remove the crankshaft rear oil slinger.

Fig 1: Removing Crankshaft Rear Oil Slinger Using Special Tool
Courtesy of FORD MOTOR CO.
Use the special tools to remove the crankshaft rear oil seal.

Fig 2: Removing Crankshaft Rear Oil Seal Using Special Tool
Courtesy of FORD MOTOR CO.
