Removal & Installation
WARNING: This page is about a different car, the 2003 Ford Pickup, 2003 Ford F550 Super Duty, 2003 Ford F450 Super Duty, 2003 Ford Excursion, and 2003 Ford Cab & Chassis. However, it is still accessible from the selected car via links, so may be relevant.
Disconnect negative battery cable. Raise and support vehicle. Disconnect hoses and electrical connectors. Remove charcoal canister bolt. See Fig 1. Remove charcoal canister. See Fig 2. Remove canister vent solenoid. See Figure. To install, reverse removal procedure. Perform after repair procedure. See AFTER REPAIR PROCEDURE .
