Section 71 (Steering Column)
>>
Diagnosis And Testing
>>
Steering Column - Tilt/Telescopic Motors
>>
Instrument Cluster Module (ICM) Diagnostic Trouble Code (DTC) Index
Instrument Cluster Module (ICM) Diagnostic Trouble Code (DTC) Index
WARNING:
This page is about a different car, the 2002 Lincoln LS. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Instrument Cluster Module (ICM) Diagnostic Trouble Code (DTC) Index (B2328, B2332 & B2351)
Courtesy of FORD MOTOR CO.
