Pinpoint Test B: DTC B1485 - Brake Pedal Input Circuit Battery Short

WARNING: This page is about a different car, the 2002 Lincoln LS. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Pinpoint Test B: DTC B1485 - Brake Pedal Input Circuit Battery Short
G01102875Courtesy of FORD MOTOR CO.
