Crankshaft Front Seal: Installation

WARNING: This page is about a different car, the 2005 Ford Pickup, 2005 Ford F550 Super Duty, 2005 Ford F450 Super Duty, and 2005 Ford Cab & Chassis. However, it is still accessible from the selected car via links, so may be relevant.
  1. Thoroughly clean the crankshaft front seal mounting surface.
  2. Apply High Strength Threadlocker to the outer circumference of the leading edge of the crankshaft.
    3. NOTE: New seal and wear sleeve must not be separated.
    Fig 1: Installing Oil Seal And Wear Sleeve Assembly Using Special Tool
    G03907068Courtesy of FORD MOTOR CO.
  3. Using the special tool, install the oil seal and wear sleeve assembly.
  4. Install the crankshaft damper. For additional information, refer to CRANKSHAFT PULLEY .
