Rear Door Window Glass - SuperCab: Installation

WARNING: This page is about a different car, the 2005 Ford Pickup, 2005 Ford F550 Super Duty, 2005 Ford F450 Super Duty, and 2005 Ford Cab & Chassis. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the release liner from the butyl seal around the window before installing the window.
    Fig 1: Removing Release Liner
    G03925736Courtesy of FORD MOTOR CO.
  2. Install the window frame and glass.
    • Position the window frame and glass.
      • NOTE: Loosely install nuts and clips before tightening.
    • Tighten the nuts.
  3. Install the rear door window trim panel.
  4. Install the rear door window latch.
  5. Clean excess butyl from window area.
