Reverse Clutch: Notes
WARNING: This page is about a different car, the 2005 Ford Pickup. However, it is still accessible from the selected car via links, so may be relevant.
SPECIAL TOOL SPECIFICATIONS
| Dial Indicator Gauge with Holding Fixture 100-002 (TOOL-4201-C) | |
| Compressor, Clutch Spring 307-015 (T65L-77515-A) | |
| Protector, Transmission Reverse Clutch Outer Fluid Seal 307-424 | |
| Protector, Transmission Reverse Clutch Inner Fluid Seal 307-425 | |
| Compressor, Clutch Spring 307-086 (T80L-77405-A) |
MATERIAL SPECIFICATIONS
| Item | Specification |
|---|---|
| MERCON® V Automatic Transmission Fluid XT-5-QM | MERCON® V |
