Crankshaft Pulley: Notes
WARNING: This page is about a different car, the 2005 Ford Pickup. However, it is still accessible from the selected car via links, so may be relevant.
SPECIAL TOOLS
| Remover, Crankshaft Vibration Damper 303-009 (T58P-6316-D) | |
| Installer, Crankshaft Vibration Damper 303-102 (T74P-6316-B) | |
| Strap Wrench 303-D055 (D85L-6000-A) or equivalent |
MATERIALS
| Item | Specification |
|---|---|
| Motorcraft SAE 5W-20 Premium Synthetic Blend Motor Oil XO-5W20-QSP (in Canada Motorcraft SAE 5W-20 Super Premium Motor Oil CXO-5W20-LSP12) or equivalent | WSS-M2C930-A |
| Silicone Gasket Remover ZC-30 | - |
| Motorcraft Metal Surface Prep ZC-31 | - |
| Silicone Gasket and Sealant TA-30 | WSE-M4G323-A4 |
