Removal and Installation

WARNING: This page is about a different car, the 2005 Ford Pickup, 2005 Ford F550 Super Duty, 2005 Ford F450 Super Duty, and 2005 Ford Cab & Chassis. However, it is still accessible from the selected car via links, so may be relevant.

WARNING: When performing maintenance on the starting system, be aware heavy gauge leads are connected to the battery. Make sure protective caps are in place when maintenance is complete.

Disconnect the battery ground cable (14301). For additional information, refer to BATTERY, MOUNTING AND CABLES .
With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to JACKING AND LIFTING
Remove starter solenoid protective cap.

Fig 1: Removing Starter Solenoid Protective Cap
Courtesy of FORD MOTOR CO.
Disconnect the starter motor electrical connections.

Fig 2: Disconnecting Starter Motor Electrical Connections
Courtesy of FORD MOTOR CO.
Remove the three bolts and the starter.

Fig 3: Removing Three Bolts And Starter
Courtesy of FORD MOTOR CO.
To install, reverse the removal procedure.
- Install the upper and lower starter bolts finger tight.
- Tighten the upper bolt.
- Tighten the lower bolts.
