Removal And Installation: Flywheel: Removal

WARNING: This page is about a different car, the 2005 Ford Pickup, 2005 Ford F550 Super Duty, 2005 Ford F450 Super Duty, and 2005 Ford Cab & Chassis. However, it is still accessible from the selected car via links, so may be relevant.
  1. Prepare the vehicle for flywheel removal.
    1. Remove the Transmission. For additional information, refer to MANUAL TRANSAXLE/TRANSMISSION - ZF 6-SPEED .
    2. Remove the clutch pressure plate and disc. For additional information, refer to CLUTCH DISC AND PRESSURE PLATE .
  2. Remove the flywheel.
    1. Remove the bolts. Install the guide studs.
    2. Remove the bolts.
    3. Remove the reinforcing ring (6.0L) and the flywheel and ring gear assembly.
    4. Remove the guide studs.
      Fig 1: Removing Flywheel (6.0L)
      G03923344Courtesy of FORD MOTOR CO.
      Fig 2: Removing Flywheel (5.4L And 6.8L)
      G03923345Courtesy of FORD MOTOR CO.
