Transmission Filler Tube: Removal

WARNING: This page is about a different car, the 2005 Ford RV Cutaway, 2005 Ford Econoline, 2005 Ford E450 Super Duty, and 2005 Ford Cutaway. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the fluid level indicator.
    Fig 1: Removing Fluid Level Indicator
    G03889043Courtesy of FORD MOTOR CO.
  2. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to JACKING & LIFTING .
  3. Remove the transmission fluid fill tube nut.
    Fig 2: Removing Transmission Fluid Fill Tube Nut
    G03886397Courtesy of FORD MOTOR CO.
  4. Remove the transmission fluid filler tube.
    Fig 3: Removing Transmission Fluid Filler Tube
    G03889045Courtesy of FORD MOTOR CO.
  5. Inspect the O-ring seal for damage.
    Fig 4: Inspecting O-Ring Seal For Damage
    G03889046Courtesy of FORD MOTOR CO.
