Center Support: Assembly

WARNING: This page is about a different car, the 2005 Ford RV Cutaway, 2005 Ford Econoline, 2005 Ford E450 Super Duty, and 2005 Ford Cutaway. However, it is still accessible from the selected car via links, so may be relevant.
  1. Follow the disassembly procedure in reverse order.
    • Lightly lubricate the thrust washer with petroleum jelly to hold it in place during assembly.
    • Install new seals.
  2. After the center support is completely assembled, apply air to the port and verify the function of the piston.
    Fig 1: Installing New Seals
    G03889428Courtesy of FORD MOTOR CO.
