Removal and Installation

WARNING: This page is about a different car, the 2005 Ford RV Cutaway, 2005 Ford Econoline, 2005 Ford E450 Super Duty, and 2005 Ford Cutaway. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the brake pads. For additional information, refer to BRAKE PADS .
  2. Remove the front disc brake caliper anchor plate.
    1. Remove the two front disc brake caliper anchor plate bolts.
    2. Remove the front disc brake caliper anchor plate.
      Fig 1: Removing Front Disc Brake Caliper Anchor Plate
      G03884652Courtesy of FORD MOTOR CO.
  3. To install, reverse the removal procedure.
