Section 75 (Automatic Transmission - Diagnosis - 4R70W): Identification
WARNING: This page does not describe the selected car, but rather 11 other vehicles, including the 2002 Mercury Grand Marquis, 2002 Lincoln Town Car, 2002 Ford Crown Victoria, 2001 Mercury Mountaineer, and 2001 Mercury Grand Marquis. However, it is still accessible from the selected car via links, so may be relevant.
4R70W transmission is identified by a code letter on lower line of vehicle certification label. This code can be found directly under the TR designation. See Fig 2 . Label is attached to driver's door lock post. See TRANSMISSION CODE LETTER CHART . Transmission model may be identified by service identification tag attached to right side of transmission case or fluid pan. Tag shows transmission model, assembly number and serial number. See Fig 1 . For rear axle gear ratio, see code directly under the AXLE designation.
TRANSMISSION CODE LETTER CHART
| Application | Code Letter | |
|---|---|---|
| All Models | ||
| Sharonville Plant (4R70W) | H | |
| Livonia Plant (4R70W) | U | |
