Key On Engine Off (KOEO) Injector Electrical Self-Test (Click Test)
WARNING: This page does not describe the selected car, but rather 9 other vehicles, including the 2004 Ford RV Cutaway, 2004 Ford Pickup, 2004 Ford F550 Super Duty, 2004 Ford F450 Super Duty, and 2004 Ford Excursion. However, it is still accessible from the selected car via links, so may be relevant.
Key On Engine OFF (KOEO) injector electrical self-test (click test) is a functional test of the FICM performed on demand with the key on and the engine off. This test determines if the injector circuits and solenoids are electrically operating without fault. All injectors will click (audible feedback of the injector solenoids energizing the injector valves) together. Then each injector 1 through 8 is cycled approximately one second in sequence. This process is repeated three times during the entire test. If a fault is detected by the FICM, a CAN message is sent to the PCM. Corresponding fault DTCs are displayed at the end of the self-test.
