Special Tool(s)

WARNING: This page is about a different car, the 2003 Ford RV Cutaway, 2003 Ford Econoline, 2003 Ford E550 Super Duty, 2003 Ford E450 Super Duty, and 2003 Ford Cutaway. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Identifying Special Service Tool
G03461979Courtesy of FORD MOTOR CO.
  1. Remove the valve tappets.
  2. Use a Dial Indicator Gauge with Holding Fixture to measure camshaft end play.
  3. Position the camshaft to the rear of the cylinder block.
  4. Zero the indicator.
  5. Move the camshaft to the front of the cylinder block. Note and record the camshaft end play.
    • If the camshaft end play exceeds specifications, install a new camshaft thrust plate. Refer to IN-VEHICLE REPAIR in the appropriate ENGINE article for the procedure.
    Fig 2: Removing Valve Tappets
    G03461980Courtesy of FORD MOTOR CO.
