Removal and Installation

WARNING: This page is about a different car, the 2004 Ford Pickup, 2004 Ford F550 Super Duty, 2004 Ford F450 Super Duty, 2004 Ford Excursion, and 2004 Ford Cab & Chassis. However, it is still accessible from the selected car via links, so may be relevant.

Remove the rear seat load floor-to-floor bolt.

Fig 1: Removing Rear Seat Load Floor-To-Floor Bolt
Courtesy of FORD MOTOR CO.
Remove the six load floor bolts and remove the load floor assembly.

Fig 2: Removing Load Floor Assembly
Courtesy of FORD MOTOR CO.
Remove the left seat riser-to-floor bolt.

Fig 3: Removing Left Seat Riser-To-Floor Bolt
Courtesy of FORD MOTOR CO.
Remove the two right seat riser-to-floor bolts.

Fig 4: Removing Two Right Seat Riser-To-Floor Bolts
Courtesy of FORD MOTOR CO.
Remove the two right rear seat riser-to-floor nuts.

Fig 5: Removing Two Right Rear Seat Riser-To-Floor Nuts
Courtesy of FORD MOTOR CO.
Remove the left rear seat riser-to-floor nut.

Fig 6: Removing Left Rear Seat Riser-To-Floor Nut
Courtesy of FORD MOTOR CO.

NOTE: Removing the rear seat requires more than one technician.

Remove the 60/40 rear seat assembly.
To install, reverse the removal procedure.
Check the active restraint system for correct operation. Refer to SAFETY BELT SYSTEM .
