Selective Thrust Washer - No. 1 Specification Chart
WARNING: This page is about a different car, the 2004 Ford RV Cutaway, 2004 Ford Econoline, and 2004 Ford Cutaway. However, it is still accessible from the selected car via links, so may be relevant.
SELECTIVE THRUST WASHER - NO. 1 SPECIFICATION CHART
| Item | Specification |
|---|---|
| Green thickness mm (inch) | 1.217-1.371 (0.050-0.054) |
| Yellow thickness mm (inch) | 1.727-1.828 (0.068-0.072) |
| Natural thickness mm (inch) | 2.159-2.260 (0.085-0.089) |
| Red thickness mm (inch) | 2.590-2.692 (0.102-0.106) |
| Blue thickness mm (inch) | 3.022-3.124 (0.119-0.123) |
