Band And Clutch Application Chart A
WARNING: This page is about a different car, the 2004 Ford RV Cutaway, 2004 Ford Econoline, and 2004 Ford Cutaway. However, it is still accessible from the selected car via links, so may be relevant.
BAND AND CLUTCH APPLICATION CHART A
| Gear | Overdrive Band | Intermediate Clutch | Low/Reverse Band | Reverse Clutch | Forward Clutch | Direct Clutch |
|---|---|---|---|---|---|---|
| REVERSE | - | - | A | A | - | - |
| 1st GEAR MANUAL LOW | - | - | A | - | A | - |
| 2nd GEAR MANUAL LOW | A | - | A | - | A | - |
| 1st GEAR (D) (Overdrive) | - | - | - | - | A | - |
| 2nd GEAR (D) (Overdrive) | - | A | - | - | A | - |
| 3rd GEAR (D) (Overdrive) | - | A | - | - | - | A |
| 4th GEAR (D) (Overdrive) | A | A | - | - | - | A |
| A = Applied | ||||||
