Removal and Installation

WARNING: This page is about a different car, the 2004 Ford RV Cutaway, 2004 Ford Econoline, 2004 Ford E450 Super Duty, and 2004 Ford Cutaway. However, it is still accessible from the selected car via links, so may be relevant.

Remove the ignition coil. For additional information, refer to IGNITION COIL-ON-PLUG .

NOTE: Remove any foreign material from the spark plug wells with compressed air before removing the spark plugs.

Fig 1: Removing Spark Plugs

Courtesy of FORD MOTOR CO.

Remove the spark plugs.
Inspect the spark plugs. For additional information, refer to ENGINE SYSTEM-GENERAL INFORMATION .
To install, reverse the removal procedure.

Fig 2: Inspecting Spark Plugs
Courtesy of FORD MOTOR CO.
