Item 48: Overdrive Servo Cover Retaining Ring Disassembly Note

WARNING: This page is about a different car, the 2004 Mercury Mountaineer and 2004 Ford Explorer. However, it is still accessible from the selected car via links, so may be relevant.

CAUTION: Servo cover is under spring tension.

Fig 1: Removing Overdrive Servo Cover Retaining Ring And Cover

Courtesy of FORD MOTOR CO.

Using the special tool, remove the overdrive servo cover retaining ring and cover.
