Removal and Installation

WARNING: This page is about a different car, the 2004 Mercury Mountaineer and 2004 Ford Explorer. However, it is still accessible from the selected car via links, so may be relevant.
  1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to JACKING & LIFTING .
  2. Remove the cooling fan and the cooling fan shroud. For additional information, refer to ENGINE COOLING .
  3. Remove the accessory drive belt. For additional information, refer to ACCESSORY DRIVE BELT, TENSIONER AND PULLEY  .
  4. Remove the parts in the order indicated in the following illustration and table.
  5. To install, reverse the removal procedure.
    Fig 1: Removing Crankshaft Pulley and Crankshaft Seal - Late Build
    G03180469Courtesy of FORD MOTOR CO.
