EGR System Components
WARNING: This page is about a different car, the 2004 Mercury Mountaineer and 2004 Ford Explorer. However, it is still accessible from the selected car via links, so may be relevant.
The EGR system returns a portion of the exhaust gas to the intake manifold to reduce the combustion temperature. This results in lower nitrous oxide formation.
The PCM controls the EGR system module. When the EGR system module valve opens, exhaust gas flows to the intake manifold.
The PCV valve:
- controls the amount of ventilating air and blow-by gases going to the intake manifold.
- prevents a backfire from reaching the crankcase.
The EGR system module to exhaust manifold tube:
- connects the exhaust manifold to the EGR valve.
The EGR system module transducer:
- monitors the EGR system module flow rate through the EGR to exhaust manifold tube.
- sends an EGR system module flow rate signal to the PCM.
The EGR vacuum regulator solenoid uses input from the PCM to change the EGR system module operation.
