Item 16: Seat Side Air Bag Nuts Assembly Note
WARNING: This page is about a different car, the 2004 Mercury Monterey and 2004 Ford Freestar. However, it is still accessible from the selected car via links, so may be relevant.
- Position the side air bag module onto the front seat backrest frame mounting bracket and install the nuts.
- Route the side air bag module wire harness to the seat backrest frame.
WARNING:
Inspect the mounting surfaces of the side air bag module and the seat back frame mounting bracket for any foreign objects, before installing the side air bag module. If any foreign objects are found, remove them. Failure to do so may result in personal injury, in the event of an air bag deployment.
WARNING:
Inspect the side air bag deployment chute and the side air bag cavity in the seat back pad for any foreign objects. If any foreign objects are found remove them. Failure to do so may result in personal injury in the event of an air bag deployment.
WARNING:
Before installing the side air bag module, check it for damage and foreign objects. If the air bag module is damaged, replace it. If any foreign objects are found, remove them. Failure to do so may result in personal injury, in the event of an air bag deployment.
WARNING:
Do not disconnect the wire connector at the seat side air bag module. This is a permanent connection. Doing so may result in accidental air bag deployment, which may result in personal injury.
NOTE:
If installing a new seat side air bag module, use new retaining nuts. If the same seat side air bag module is to be reused then reuse the seat side air bag module nuts.
