Cowl Panel Grille: Notes
WARNING: This page is about a different car, the 2004 Mercury Monterey and 2004 Ford Freestar. However, it is still accessible from the selected car via links, so may be relevant.
- Remove the parts in the order indicated in the following illustration and table.
To remove individual parts, only carry out the listed steps:
| Part |
Steps |
| LH pivot arm |
1, 3 |
| RH pivot arm |
1, 2 |
| Cowl vent screen assembly |
1-5 |
Courtesy of FORD MOTOR CO.
- To install, reverse the removal procedure.
