Diagnosis By Symptom: Notes
WARNING: This page is about a different car, the 2004 Ford Ranger. However, it is still accessible from the selected car via links, so may be relevant.
The Diagnosis by Symptom Index gives the technician diagnostic information, direction and suggests possible components, using a symptom as a starting point.
The Diagnosis by Symptom Index is divided into two categories: Electrical Routines, indicated by 200 series numbers and Hydraulic/Mechanical Routines, indicated by 300 series numbers. The Electrical Routines list the possible electrical components that could cause or contribute to the symptom described. The Hydraulic/Mechanical Routines list the possible hydraulic or mechanical components that could cause or contribute to the symptom described.
