Drive Pinion Seal: Removal

WARNING: This page is about a different car, the 2002 Ford RV Cutaway, 2002 Ford Econoline, 2002 Ford E550 Super Duty, 2002 Ford E450 Super Duty, and 2002 Ford Cutaway. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the pinion flange (4851). For additional information, refer to DRIVE PINION FLANGE .
  2. Using a screwdriver, force the metal flange of the rear axle drive pinion seal (4676) up and strike it with a hammer.
    Fig 1: Forcing Rear Axle Drive Pinion Seal Flange Up
    G01948096Courtesy of FORD MOTOR CO.
  3. Install gripping pliers, and remove the seal.
    Fig 2: Removing Rear Axle Drive Pinion Seal
    G01948097Courtesy of FORD MOTOR CO.
