Item 3: Brake Caliper Assembly Removal Note

WARNING: This page is about a different car, the 2003 Lincoln LS. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the caliper flow bolt and the two copper washers. Discard the copper washers.
    Fig 1: Removing Caliper Flow Bolt And Copper Washers
    G01285343Courtesy of FORD MOTOR CO.
