Removal and Installation

WARNING: This page is about a different car, the 2004 Ford RV Cutaway, 2004 Ford Econoline, 2004 Ford E450 Super Duty, and 2004 Ford Cutaway. However, it is still accessible from the selected car via links, so may be relevant.

Remove the wheel and tire assembly.
Use Hi-Lift Jack to support the rear axle (4001).

Fig 1: Exploded View Of Rear Spring
Courtesy of FORD MOTOR CO.
Disconnect the lower end of the rear shock absorber (18125).
Separate the rear spring (5560) from the rear axle.
1. Remove the nuts.
2. Remove the U-bolts.
3. Remove the rear spring plate (5796).

  Fig 2: Spring Replacement
  Courtesy of FORD MOTOR CO.
Remove the rear spring.
1. Remove the bolt and nut.
2. Remove the bolt and nut.
3. Remove the rear spring.

  Fig 3: Rear Leaf Spring Replacement
  Courtesy of FORD MOTOR CO.
Follow the removal procedure in reverse order.
