Engine Mount (View 2 of 3)

WARNING: This page is about a different car, the 2011 Lincoln MKZ and 2011 Ford Fusion. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Engine Mount Replacement Components With Torque Specifications (View 2 Of 3)
G07784526Courtesy of FORD MOTOR CO.
ITEM DESCRIPTION

Item Part Number Description
1 14197 Wiring harness retainer
2 W707398 Engine coolant degas bottle-to-fender bolt
3 W709603 Engine coolant degas bottle-to-fender nut
4 8A080 Engine coolant degas bottle
