Wheel Studs: Notes
WARNING: This page is about a different car, the 2010 Lincoln Town Car. However, it is still accessible from the selected car via links, so may be relevant.
Special Tools
| Illustration |
Tool Name |
Tool Number |
 Courtesy of FORD MOTOR CO.
|
C-Frame and Screw Assembly |
211-023 (T74P-3044-A1) |
Courtesy of FORD MOTOR CO.
| Item |
Part Number |
Description |
| 1 |
1125 |
Brake disc |
| 2 |
2B120 LH/ 2B121 RH |
Disc brake caliper |
| 3 |
W707287-S |
Wheel stud |
| 4 |
W707589 |
Disc brake caliper anchor plate bolts (2 required) |
