Engine Front Cover (View 1 of 3)
WARNING: This page is about a different car, the 2010 Mercury Mariner and 2010 Ford Escape. However, it is still accessible from the selected car via links, so may be relevant.
Courtesy of FORD MOTOR CO. ITEM DESCRIPTION
| Item |
Part Number |
Description |
| 1 |
W709986 |
Generator bolt |
| 2 |
10300 |
Generator |
| 3 |
W710416 |
Generator stud |
| 4 |
W520414 |
Generator stud nut (2 required) |
| 5 |
6B209 |
Accessory drive belt tensioner |
| 6 |
W503297 |
Accessory drive belt tensioner bolt (3 required) |
