Engine Mount (View 2 of 3)

WARNING: This page is about a different car, the 2010 Lincoln MKZ and 2010 Ford Fusion. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Engine Mount Replacement Components With Torque Specifications (2 Of 3)
G06269813Courtesy of FORD MOTOR CO.
ITEM DESCRIPTION TABLE

Item Part Number Description
1 14197 Wiring harness retainer
2 W707398 Engine coolant degas bottle-to-fender bolt
3 W709603 Engine coolant degas bottle-to-fender nut
4 8A080 Engine coolant degas bottle
