Solenoid Body Assembly: Removal

WARNING: This page is about a different car, the 2006 Ford Pickup, 2006 Ford F550 Super Duty, 2006 Ford F450 Super Duty, and 2006 Ford Cab & Chassis. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the transmission fluid pan, gasket and filter. For additional information, refer to FLUID PAN, GASKET AND FILTER .
  2. Disconnect the solenoid body electrical connector.
    Fig 1: Identifying Solenoid Body Electrical Connector
    G03889052Courtesy of FORD MOTOR CO.
    3. NOTE: While lowering the solenoid body, the manual valve may fall out of the solenoid body.
  3. Remove the solenoid body.
    1. Disconnect the transmission range (TR) sensor electrical connector.
    2. Remove the solenoid body bolts.
    3. Remove the solenoid body.
      Fig 2: Locating Solenoid Body Bolts
      G04649589Courtesy of FORD MOTOR CO.
  4. Remove the solenoid body gasket.
    Fig 3: View Of Solenoid Body Gasket
    G03889054Courtesy of FORD MOTOR CO.
