Manual Control Lever Shaft And Seal: Notes

WARNING: This page is about a different car, the 2006 Ford Pickup, 2006 Ford F550 Super Duty, 2006 Ford F450 Super Duty, and 2006 Ford Cab & Chassis. However, it is still accessible from the selected car via links, so may be relevant.
SPECIAL TOOL(S) SPECIFICATIONS

G04649674Courtesy of FORD MOTOR CO.
 Roll Pin Set
211-S060 (T78P-3504-N)
G04649675Courtesy of FORD MOTOR CO.
 Remover, Pilot Bearing
308-001 (T58L-101-B)
G04649676Courtesy of FORD MOTOR CO.
 Installer, Shift Shaft Fluid Seal
307-002 (TOOL-77288)
Fig 1: Identifying Manual Control Lever Shaft And Seal Components
G04649677Courtesy of FORD MOTOR CO.
