Removal and Installation

WARNING: This page is about a different car, the 2006 Ford Pickup, 2006 Ford F550 Super Duty, 2006 Ford F450 Super Duty, and 2006 Ford Cab & Chassis. However, it is still accessible from the selected car via links, so may be relevant.

Remove the steering column cover.

Fig 1: Identifying Steering Column Cover
Courtesy of FORD MOTOR CO.
Release the clips and detach the in-vehicle temperature sensor.

Fig 2: Locating In-Vehicle Temperature Sensor
Courtesy of FORD MOTOR CO.
Disconnect the electrical connector and the venturi hose and remove the in-vehicle temperature sensor.

Fig 3: Locating Electrical Connector And Venturi Hose
Courtesy of FORD MOTOR CO.
To install, reverse the removal procedure.
