Cylinder Head: Notes
WARNING: This page is about a different car, the 2006 Mercury Mariner and 2006 Ford Escape. However, it is still accessible from the selected car via links, so may be relevant.
SPECIAL TOOL(S)
| Compressor, Valve Spring 303-350 (T89P-6565-A) |
|
| Compressor, Valve Spring 303-300 (T87C-6565-A) |
|
| Compressor, Valve Spring 303-472 (T94P-6565-AH) |
|
| Remover, Valve Stem Oil Seal 303-468 (T94P-6510-AH) |
|
| Installer, Valve Stem Oil Seal 303-470 (T94P-6510-CH) |
|
| Slide Hammer 307-005 (T59L-100-B) |
MATERIALS
| Item | Specification |
|---|---|
| Motorcraft SAE 5W-20 Premium Synthetic Blend Motor Oil XO-5W20-QSP (US); Motorcraft SAE 5W-20 Super Premium Motor Oil CXO-5W20-LSP12 (Canada); or equivalent |
WSS-M2C930-A |
| Multi-Purpose Grease XG-4 and/or XL-5 |
ESB-M1C93-B |
