Trailer Tow RH Turn Relay C1187, Trailer Tow LH Turn Relay C1188, Trailer Tow Reversing Lamp Relay C4023

WARNING: This page is about a different car, the 2005 Mercury Mountaineer and 2005 Ford Explorer. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Identifying C1187 And C4023 Connector Pinouts
G03945671Courtesy of FORD MOTOR CO.
