Axle Tube Bearing: Removal

WARNING: This page is about a different car, the 2005 Mercury Mountaineer and 2005 Ford Explorer. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the RH halfshaft. For additional information, refer to FRONT DRIVE HALFSHAFTS .
  2. Remove the RH axle shaft.
    Fig 1: Removing RH Axle Shaft
    G03912816Courtesy of FORD MOTOR CO.
  3. Using the special tool and a suitable slide hammer, remove the axle shaft oil seal.
    Fig 2: Removing Axle Shaft Oil Seal
    G03944361Courtesy of FORD MOTOR CO.
  4. Using the special tool and a suitable slide hammer, remove the axle tube bearing.
    Fig 3: Removing Axle Tube Bearing
    G03944362Courtesy of FORD MOTOR CO.
  5. Clean the bearing and seal mounting surfaces.
