Disassembly and Assembly

WARNING: This page is about a different car, the 2005 Ford Pickup, 2005 Ford F550 Super Duty, 2005 Ford F450 Super Duty, and 2005 Ford Cab & Chassis. However, it is still accessible from the selected car via links, so may be relevant.

Remove the rear seat quad bucket backrest. For additional information, refer to REAR SEAT BACKREST - CREW CAB, QUAD BUCKET in this article.
Release the J-clip.

Fig 1: Releasing J-Clip
Courtesy of FORD MOTOR CO.
Using a suitable tool, release the handle clip and pull to remove the handle.

Fig 2: Removing Handle
Courtesy of FORD MOTOR CO.

NOTE: Use care when separating the backrest trim cover from the hook-and-loop strip, or the hook-and-loop strip can be torn from the seat backrest foam.

Fig 3: Releasing Hook-And-Loop Strip

Courtesy of FORD MOTOR CO.

Invert the backrest material and release the hook-and-loop strip.
Remove the hog rings and remove the backrest trim cover.

Fig 4: Removing Hog Rings And Backrest Trim Cover
Courtesy of FORD MOTOR CO.
Remove the backrest foam pad from the backrest frame.

Fig 5: Removing Backrest Foam Pad From Backrest Frame
Courtesy of FORD MOTOR CO.
Remove the two bolts and the recliner assembly.

Fig 6: Removing Bolts And Recliner Assembly - With Torque Specifications
Courtesy of FORD MOTOR CO.
Compress the lumbar assembly and remove the lumbar cable anchor.

Fig 7: Removing Lumbar Cable Anchor
Courtesy of FORD MOTOR CO.
Slide the lumbar cable end and remove the cable from the lumbar assembly.

Fig 8: Removing Cable From Lumbar Assembly
Courtesy of FORD MOTOR CO.
Release the four lumbar retainer clips (two shown) and remove the lumbar assembly.

Fig 9: Removing Lumbar Assembly
Courtesy of FORD MOTOR CO.
To assemble, reverse the disassembly procedure.
