Fuel Tank - Forward Aft-Axle: Removal

WARNING: This page is about a different car, the 2004 Ford RV Cutaway, 2004 Ford Econoline, 2004 Ford E450 Super Duty, and 2004 Ford Cutaway. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the aft-axle fuel tank assembly. For additional information, refer to FUEL TANK - AFT-AXLE ASSEMBLY .
  2. Disconnect the fuel tank balance tube from the forward aft-axle fuel tank solenoid valve.
    Fig 1: Disconnecting Fuel Tank Balance Tube From Forward AFT-Axle Fuel Tank Solenoid Valve
    G02766116Courtesy of FORD MOTOR CO.
  3. Remove the forward aft-axle fuel tank.
    1. Remove the fuel tank support strap retaining nuts.
    2. Remove the forward aft-axle fuel tank.
    Fig 2: Removing Forward AFT-Axle Fuel Tank
    G02766117Courtesy of FORD MOTOR CO.
