Differential Ring and Pinion - Rear Axle: Material
WARNING: This page is about a different car, the 2004 Mercury Mountaineer and 2004 Ford Explorer. However, it is still accessible from the selected car via links, so may be relevant.
MATERIAL SPECIFICATIONS
| Item |
Specification |
| Premium Long-Life Grease XG-1-C |
ESA-M1C75-B |
| Threadlock and Sealer TA-25 |
WSK-M2G351-A5 |
| Stud and Bearing Mount TA-27 |
WSK-M2G349-A1 |
| Silicone Gasket and Sealant F7AZ-19554-EA |
WSE-M4G323-A4 |
