Special Tool(s)

WARNING: This page is about a different car, the 2002 Ford Ranger. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Identifying Special Tool(s)

Courtesy of FORD MOTOR CO.

Remove the air cleaner outlet pipe.
Remove the accessory drive belt. For additional information, refer to SPECIFICATIONS & DRIVE BELT ROUTING .
Using the special tool, loosen the mechanical fan nut.

Fig 2: Loosening Mechanical Fan Nut
Courtesy of FORD MOTOR CO.
Remove the fan and clutch assembly.

Fig 3: Removing Fan & Clutch Assembly
Courtesy of FORD MOTOR CO.
To install, reverse the removal procedure.
