Shift Concerns: Timing Concerns - Erratic/Hunting

WARNING: This page is about a different car, the 2003 Mercury Marauder, 2003 Mercury Grand Marquis, and 2003 Ford Crown Victoria. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Diagnostic Chart - Shift Concerns: Timing Concerns - Erratic/Hunting
G01608189Courtesy of FORD MOTOR CO.
