Drive Pinion Seal: Removal

WARNING: This page is about a different car, the 2003 Ford Ranger. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the pinion flange (4851). For additional information, refer to DRIVE PINION FLANGE .
  2. Using a screwdriver, force the rear axle drive pinion seal metal flange up and strike it with a hammer.
    Fig 1: Using A Screwdriver To Force Rear Axle Drive Pinion Seal Metal Flange Up
    G01291454Courtesy of FORD MOTOR CO.
  3. Using gripping pliers and a hammer, remove the seal.
    Fig 2: Removing Seal Using Gripping Pliers & Hammer
    G01291455Courtesy of FORD MOTOR CO.
