Section 52 (Vacuum Diagrams - 2.5L): Introduction
WARNING: This page is about a different car, the 1995 Mazda Millenia. However, it is still accessible from the selected car via links, so may be relevant.
This article contains underhood views or schematics of vacuum hose routing. Use these vacuum diagrams during the visual inspection in BASIC TESTING - 2.5L article. This will assist in identifying improperly routed vacuum hoses which cause driveability and/or computer indicated malfunctions.
