Torque Specifications
WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 1996 Ford Pickup, 1996 Ford Econoline, 1996 Ford Club Wagon, 1996 Ford Cab & Chassis, and 1995 Ford Pickup. However, it is still accessible from the selected car via links, so may be relevant.
TORQUE SPECIFICATIONS
| Application |
Ft. Lbs. (N.m) |
| A/C Compressor Bolts |
| Short |
22-30 (30-41) |
| Long |
21-31 (28-42) |
| Bellhousing-To-Engine Bolt |
40-50 (54-68) |
| Camshaft Thrust Plate Bolt |
12-18 (16-24) |
| Connecting Rod Cap Nut |
40-45 (54-61) |
| Crankshaft Damper Bolt |
130-150 (176-203) |
| Cylinder Head Bolt |
| Step 1 |
45-55 (61-75) |
| Step 2 |
Additional 80-100 degrees |
| Front Engine Mount Nut |
54-74 (73-100) |
| Flexplate-To-Torque Converter Bolt |
20-34 (27-46) |
| Flywheel-To-Crankshaft Bolt |
75-85 (102-115) |
| Front Cover Bolt |
12-18 (16-24) |
| Fuel Supply Manifold Bolt |
12-15 (16-20) |
| Generator Bolt |
22-30 (30-41) |
| Lower Intake & Exhaust Manifold Assembly Nut |
22-32 (30-43) |
| Main Bearing Cap Bolt |
60-70 (81-95) |
| Oil Filter Adapter Bolt |
15-35 (20-47) |
| Oil Pan Bolt |
15-18 (20-24) |
| Oil Pump Pick-Up Tube Nut |
10-15 (14-20) |
| Oil Pump-To-Cylinder Block Bolt |
10-15 (14-20) |
| Power Steering Pump Bracket Bolt |
30-40 (41-54) |
| Rocker Arm Bolt |
17-23 (23-31) |
| Starter Bolt |
15-20 (20-27) |
| Throttle Body-To-Upper Intake Manifold Bolt |
14-20 (19-27) |
| Upper Intake Manifold-To-Lower Intake Manifold Bolt |
12-18 (16-24) |
| Vibration Damper Bolt |
130-150 (176-203) |
| Water Pump Bolt |
12-18 (16-24) |
| INCH Lbs. (N.m) |
| Rocker Arm Cover Bolt |
70-120 (8-14) |
