Wagon

Fig. 2 Rear Suspension:

These models also utilize an independent rear suspension. Each side consists of an upper and lower control arm, a shock absorber, a two piece spindle tension control strut and a coil spring.

The top of the shock absorber is attached to the body side panel by a rubber insulated top mount assembly and to the lower control arms by two nuts. The upper control arm attaches to the crossmember and the upper part of the spindle. The lower control arm attaches to the underbody and lower part of the spindle. The coil spring operates against the lower control arm and is located inboard of the shock absorber.
